1) Cam Analyzer v4.3 B Released  We've added many new features to our Cam Analyzer software, and are now releasing v4.3 B.  It has many enhancements, some of which include:

New Features for All Versions:

  1. You can now flip the drawing of the camshaft on the main screen to now match how you have the cam on the Cam Test Stand.  This makes it easier to keep track of what lobe you are measuring.
  2. The program has some new Example Cam Layouts, including Ford Godzilla 7.3L, Ford OHC Modular V8, Ford 292/312 Y block, Harley Davidson, and more.
  3. The program will now "talk" to our Engine Log Book Pro v1.1D, so you can pull cam specs from a Cam Analyzer file into the Engine Log Book Pro.



Cam Analyzer v4.3B Flip Cam Layout Drawing.gif (269115 bytes) click image to enlarge to show new v4.3B feature to flip cam layout drawing




New Features for the Plus Version Only:

  1. A new report type has been added: TDC Lifts, Set Cam Timing to help time the cam you measured in the engine. This report will tell you what intake and exhaust tappet lift to look for at TDC to know how advanced or retarded the cam timing will be.
  2. A new report type has been added: Lobe Analysis - Short similar to the Lobe Analysis report, but with fewer outputs. This report also includes a new output called "Drift Error", and indication of measurement accuracy.
  3. You can now specify up to 6 lobes for each cylinder.
  4. You can now specify more details when creating a cam profile from .050" inputs, .040" inputs, etc. NOTE: Profiles generated this way are still not precise enough to use for grinding custom cams.
  5. When doing one of the OHC Rocker Arm layouts with the Virtual Follower feature, the program now draws the layout as it appears from the front of the engine for Clockwise and Counter Clockwise rotations.  There is also a new choice of drawing the layout with the valve to the left or right of the cam, so 4 choices total. This will make it much easier to visualize the valve train layout.

Cam Analyzer v4.3B Swap Valve Location for OHC Rocker Arms.gif (371243 bytes)  click image to enlarge to show new v4.3B feature to swap OHC Rocker Arm Layout for Virtual Follower

Cam Analyzer v4.3B TDC Lift Report to Set Cam Timing.gif (493226 bytes) click image to enlarge to show new v4.3B report option to show TDC lift to set cam timing in the engine



New Features for the "Cam Grinder" Version Only:

  1. Now you can edit a cam profile (stretch and/or shrink the lift or duration) from data "Measured w Electronics" directly. This eliminates several steps that were required in previous version, where you had to convert to "Measured by Hand" data, do the edit you wanted, and then convert back to "Measured with Electronics".
  2. If you click on a section of a report while holding down the Ctrl key, the program presents options for making a small report of the data in that section with a small graph. This lets you quickly see if the data is has any trends, or spot data points which are quite different than the rest.
  3. You can now generate a 3D.igs file with a particular thickness for the lobe. This will produce a file of 360 1 degree segments.  If you need a Solidworks or Mastercam file consisting of arcs, there is an FAQ on our website for doing that.  for that FAQ.



Cam Analyzer v4.3B Generating .igs Manufacturing Files.gif (258546 bytes) click image to enlarge to show new v4.3B feature to export .igs files

Cam Analyzer v4.3B Quick Graphing of Report Data.gif (595333 bytes) click image to enlarge to show new v4.3B feature to do quick graph of report data

Cam Analyzer v4.3B Edit a Measured Profile in Fewer Steps 1.gif (584616 bytes) Cam Analyzer v4.3B Edit a Measured Profile in Fewer Steps 2.gif (395810 bytes) click images to enlarge to show new v4.3B feature to edit (stretch or shrink) a measured lobe in just a few steps



  for a full PDF file describing all the new v4.3B features.



If you own Cam Analyzer v4.3A now, the update costs are $125 for the std Cam Analyzer for our Cam Test Stand, $175 for the Cam Analyzer Plus, and $225 for the Cam Analyzer "Cam Grinder" version.

to email us on how update your old Cam Analyzer.

for full info on our Cam Analyzer software.

for full info on our Cam Analyzer test stand.

for full info on our Cam Analyzer youtube videos.

-------------------------------------------

2) Last September's Newsletter Here are the topics covered in our previous newsletter.  If you would like another copy of September 2025's newsletter (or any previous newsletter) for detail on these topics, visit our website at: Performance Trends Newsletters

  1. Eddy Current Dyno Controller Updates
  2. Circle Track Youtube Video
  3. Last August's Newsletter
